Electric Heat Tracing Wire Winding Production Line
Resistance or pitch is precise and stable; the operation is simple and easy to understand, requiring no high technical skills from the operators. No waste is generated during startup or shutdown. It is suitable for various types of winding electric heating cables. The machine uses a user-friendly interface, making it easy to learn. Simply input the product resistance value, and the machine will automatically adjust to produce qualified products.
Automatic opening of missing product outlets
dense winding function at the outlet
automatic control of unified winding pitch
automatic shutdown upon reaching specified length
automatic broken wire detection
external winding pouring.
| Parameter List | | |
|---|
| Resistance Wire Diameter Range | Ф0.03-0.20mm | |
| Wire Spool | Uniformly equipped with wire trays | |
| Power Supply | 220V, 50/60HZ | |
| Motor Power | one 750W unit, one 400W unit, one 370W unit | |
| Maximum Speed | Up to 4000rpm | (Note: speed is dependent on the diameter of the wire being wound) |
| Length Resistance Error | Within ±3% | |
| Pitch Error | Within ±3% | |
